Coming from Power HD is the new design waterproof servos LW-15MG and LW-30MG [2021-08-12 16:25:47]
Coming from Power HD is the new design waterproof servos LW-15MG and LW-30MG. Two servo models with different parameters for selection, 15kg/cm,30kg/cm. With stable performance,high torque,stronger locking force double, less gear slop, double ball bearings, and 25T metal spline, it's ideal for RC crawler,boat, aircraft, etc.
LW-15MG Specs:
Torque(4.8V): 9.0 kg-cm (125.0 oz/in)
Torque(6.0V): 12.5 kg-cm (173.6 oz/in)
Torque(7.2V): 15.0 kg-cm (208.3 oz/in)
Speed: 0.15 sec (4.8V) │ 0.13 sec (6.0V)│ 0.11 sec (7.2V)
Operating Voltage：4.8 ~ 7.2 DC Volts
Weight: 62 g (2.19 oz)
Bearing Type：Ball Bearing x 2
Motor Type：DC Motor
Gear Type：Copper & Aluminum
Operating Temperature：-20℃~60℃
Working frequence：1520μs / 333hz
Size：40.5 x 20.5 x 39.3 mm ( 1.59 x 0.81 x 1.55 in)
LW-30MG Specs：
Torque(4.8V): 18.0 kg-cm (250.0 oz/in)
Torque(6.0V): 23.5 kg-cm (326.4 oz/in)
Torque(7.2V): 30.0 kg-cm (416.6 oz/in)
Speed: 0.18 sec (4.8V) │ 0.16 sec (6.0V)│ 0.14 sec (7.2V)
Operating Voltage：4.8 ~ 7.2 DC Volts
Weight: 62 g (2.19 oz)
Bearing Type：Ball Bearing x 2
Motor Type：DC Motor
Gear Type：Copper & Aluminum
Operating Temperature：-20℃~60℃
Working frequence：1520μs / 333hz
Size：40.5 x 20.5 x 39.3 mm ( 1.59 x 0.81 x 1.55 in)
